Engine Type
Air cooled, 4-stroke, SOHC, 2-valve
Displacement
149 cc
Bore & stroke
57.3 mm x 57.9 mm
Compression ratio
9.6 : 1
Maximum horse power
9.1 kW (12.4PS) / 7,250 r/min
Maximum torque
13.3 N.m (1.4 kg f.m) / 5,500 r/min
Starting system type
Electric Starter
E20 Compatible
Yes
Overall Length X Width X Height
1,990mm/2,000mm(Deluxe) X 780mm X 1,080mm
Seat height
790 mm
Wheelbase
1,330 mm
Minimum ground clearance
165 mm
Kerb Weight
136 kg
Tyre size (Front)
100/80-17M/C 52P-Tubeless
Tyre size (Rear)
140/60R17M/C 63P-Radial Tubeless
ABS
Single Channel ABS
Brake type (Front)
Disc Brake(282mm)
Brake type (Rear)
Disc Brake(220mm)
Fuel tank capacity
13 L
Traction Control System
Equipped
Y-Connect
Enabled
Carburetor type /Fuel Supply
Fuel injection
Transmission type
Constant mesh, 5-speed
Brake/ Tail light (For FZ FI)
12V,21/5W x 1
Suspension type (front/rear)
Telescopic fork / 7-Step Adjustable Monocross Suspension
Headlight
LED
Taillight
LED
Clock
Digital
Speedometer
Digital
Battery
12V
ECO indicator
Equipped
Side Stand engine cut-off switch
Equipped
